YS-64''/94''/128''
Availability: | |
---|---|
Product Description
|
OVERVIEW
The YS series delivers exceptional mattress quilting precision with advanced computerized control and robust mechanical engineering. This multi-needle shuttle system combines high-speed operation with remarkable stability for manufacturers requiring premium stitch quality across diverse fabrics and applications.
High Working Speed Range: 100-1000 RPM with digital rotation adjustment
Versatile Stitch Size: Adjustable from 2-12mm for diverse quilting patterns
Impressive Production Speed: 20-200m/h for efficient manufacturing
Comprehensive Thread Break Detection: Automatic stop function for operational safety
Servo-Driven Technology: Precision control of saddle frame and rollers
Frequency Converter Spindle Control: Maintains consistent operation
Advanced Needle Row Structure: Latest design prevents maintenance issues
Premium Aluminum Alloy Frame: Oil-free, robust and durable construction
Low Vibration Performance: Stable machine structure minimizes noise
Simple Shuttle Replacement: Quick and easy maintenance process
Superior Thread Management: Minimizes breakage for continuous production
User-Friendly Pattern Editing: Rapid customization for specific requirements
High Precision Quilting: Exceptional stitch formation and pattern accuracy
Intuitive Operational Interface: Easy to operate with minimal training
|
APPLICATION
|
VIDEO
|
FAQ
Q: What is the production speed of the YS machine?
A: The production speed ranges from 20-200 meters per hour, with machine rotation speeds of 100-1000 RPM.
Q: What stitch size range does the machine offer?
A: The machine offers stitch sizes from 2-12mm, allowing for varied quilting patterns.
Q: What drive systems does the YS machine use?
A: The saddle frame and rollers are equipped with servo drives, while the spindle is controlled by a frequency converter.
Q: What is special about the needle row structure?
A: The machine features the latest design of needle row structure with an aluminum alloy needle bar frame structure that requires no oil, making it robust and durable.
Q: Does the machine have automatic thread break detection?
A: Yes, the machine features thread break detectors and will automatically stop when a thread breaks.
Q: How easy is shuttle replacement?
A: The shuttle holder design allows for quick and easy replacement of the shuttle.
Q: Does the machine require oil lubrication?
A: No, the aluminum alloy needle bar frame structure is designed to operate without oil, making it cleaner and reducing maintenance.
Q: How is the pattern editing done?
A: Pattern editing is done through the computer control system, which allows for quick and easy editing of patterns.
|
COMPARISON
Model | GM-YS-64"-3-4.5/5/6 | GM-YS-96"-3-5/6 | GM-YS-128"-2-3/6 |
Dimension(L*W*H)(mm) | 3800*1200*1800 | 4800*1200*1800 | 5700*1200*1800 |
Quilting Width(mm) | 1650mm | 2450mm | 3300mm |
The Number of Needle Rows | 3 | 3 | 2/.3 |
Space Between Needle Rows | 3"+1.5"/3"+2"/3"+3" | 3"+2"/3"+3" | 3"/3"+3" |
Space Between Needle | 19.05/25.4mm | 25.4mm | 25.4mm |
X-axis Movement Displacement | 228.6mm/228.6mm/304.8mm | 304.8mm | 254mm/304.8mm |
Thickness of Quilting | 25mm | 25mm | 25mm |
Stitch Length | 2-12mm | 2-12mm | 2-12mm |
Speed of Operation(m/hour) | 20-200 | 20-200 | 20-200 |
Model of Needle | 16#, 19# | 16#, 19# | 16#, 19# |
Quilting Speed(r/min) | 100-1000 | 100-1000 | 100-1000 |
Voltage(AC) | 380/220v,3p,50/60Hz | 380/220v,3p,50/60Hz | 380/220v,3p,50/60Hz |
Total Power | 3.5KW | 5.5KW | 7.5KW |
|
PACKAGING
