| Quantity: | |
|---|---|
AMC-620
GENMAX
| Model | AMC-620 |
| Apply for mattress type | Pocket spring mattress, Spring mattress, Sponge mattress, Latex mattress |
| Suitable packing material | PE Film |
| Thickness range for packaging film | 0.06~0.15mm |
| Max packaging film width for compress machine | 2650mm ;2800MM（two ways） |
| Max packaging film width for roll pack machine | Plus 20cm on mattress width |
| Max Mattress length for roll pack machine | 2200mm |
| Max Mattress width for roll pack machine | 2000mm |
| Max Mattress Height | 500mm |
Outlet diameter range(Adjustable)：230mm-620mm | 230mm-620mm |
| Efficiency | 35S/1pcs |
| Air Consumption | >=-0.43 m3/min ;12MM air pipe |
Air supply | 0.6-0.8MPa |
| Total powe | 43kw/ 45KW is for two packaging ways |
| Input Power cable | 4*16mm2+1*2.5mm⊃2; |
| Breaker | 100A 4P |
| Pressure | 80T |
| Total Machine Weieht | 14000kg |
| Working temperature | +5°C-+35°C |
This packing line fulfils all the operations of wrapping. compressioh, sealing and rolling with a wide range of adjust- able exit diameter.Many innovative
design,automatic fea tures enable the MAC-620 to create a high-quality ap- pearance for your packaged product.
1.Automatic mattress compressing machine:lset(two kinds of packaging way could be optional).
2.Automatic mattress folding machine:lset(could be op tional).
3.Automatic mattress roll packing machine:lset.
| Model | AMC-620 |
| Apply for mattress type | Pocket spring mattress, Spring mattress, Sponge mattress, Latex mattress |
| Suitable packing material | PE Film |
| Thickness range for packaging film | 0.06~0.15mm |
| Max packaging film width for compress machine | 2650mm ;2800MM（two ways） |
| Max packaging film width for roll pack machine | Plus 20cm on mattress width |
| Max Mattress length for roll pack machine | 2200mm |
| Max Mattress width for roll pack machine | 2000mm |
| Max Mattress Height | 500mm |
Outlet diameter range(Adjustable)：230mm-620mm | 230mm-620mm |
| Efficiency | 35S/1pcs |
| Air Consumption | >=-0.43 m3/min ;12MM air pipe |
Air supply | 0.6-0.8MPa |
| Total powe | 43kw/ 45KW is for two packaging ways |
| Input Power cable | 4*16mm2+1*2.5mm⊃2; |
| Breaker | 100A 4P |
| Pressure | 80T |
| Total Machine Weieht | 14000kg |
| Working temperature | +5°C-+35°C |
This packing line fulfils all the operations of wrapping. compressioh, sealing and rolling with a wide range of adjust- able exit diameter.Many innovative
design,automatic fea tures enable the MAC-620 to create a high-quality ap- pearance for your packaged product.
1.Automatic mattress compressing machine:lset(two kinds of packaging way could be optional).
2.Automatic mattress folding machine:lset(could be op tional).
3.Automatic mattress roll packing machine:lset.
